Design and detailing of steel structures M07

A solution that combines structural design, including the analysis of steel connections using the finite element method, and detailing for the fabrication of steel structures. It includes the OpenSees© analysis engine and options for exporting the structure to DSTV, STEP and IFC EM.11 fabrication formats.

Includes:

Original price was: R$ 46.545,00.Current price is: R$ 32.582,00.

Description:

Design and detailing steel structures M07 offers a BIM solution for the design and detailing of steel structures composed of nodes, bars and shells. It includes CYPE 3D, with options for analysing steel sections and other materials, such as concrete or the definition of generic materials. The use of ties in stiffened frames in a diagonal shape, in addition to bars with conventional behaviour, is also possible. It has the CYPE Connect tool for the modelling, design, checking and documentation of various types of steel connections. Local buckling conditions are also analysed and the rotational stiffness of each node is analysed for this type of connection. It ensures the safety and suitability of designs by carrying out analyses following the codes applicable in different countries. It includes the StruBIM Steel tool that enables the modelling or import of a BIM model for the detailing of steel structures, allowing detailed graphical documentation and export in fabrication formats (DSTV, STEP and IFC EM.11). This combination provides advanced tools to increase productivity and efficiency in the fabrication of steel structures. Together, these modules offer a versatile solution for professionals working in structural design and analysis.

Analysis and design according to standards

CYPE's software includes a wide range of standards from various countries around the world within its native features, allowing users to design and check their projects with greater speed and accuracy.

What's included?

04 PROGRAMS - 07 MODULES

APL

With this module, users can carry out the local buckling analysis of connections in CYPE Connect and StruBIM Steel.

CCS

This module is used for the modelling, design and graphical documentation of connections between bars in steel structures, in StruBIM Steel and CYPE Connect.

E11

This module allows users to export to IFC EM. 11 in StruBIM Steel.

M3D

The M3D module is the basic core of the CYPE 3D tools and is required for the operation of all program versions. When combined with C3D, it facilitates the connection between structures designed in CYPE 3D and CYPECAD by means of the "Integrated 3D Structures" feature.

OSP

It is a transverse module available for several CYPE applications that activates the operation of the OpenSees (Open System for Earthquake Engineering Simulation) analysis engine for linear and non-linear structural analysis.

SBA

The CYPE Connect Anchors - Concrete anchors module is used for designing anchors and is compatible with both CYPE Connect and StruBIM Steel. It is also used as a license to work with StruBIM Anchors ACI 318, for checking anchors in concrete elements based on the ACI standard.

SPD

Using this module in StruBIM Steel, it is possible to create sheets of elements and parts (sections and plates), assembly sheets, connection sheets and sheets with the general views of the model.

CYPE 3D

CYPE 3D is an agile and efficient program created for the analysis and design of three-dimensional structures with elements made of concrete, steel, composite concrete and steel, aluminium, timber, or any other material, and includes the sizing of connections (welded and bolted connections of rolled and welded steel I sections and hollow structural sections) and their foundations with baseplates, footings, pile caps, and strap and tie beams.

StruBIM Steel

StruBIM Steel is a program developed for the creation and maintenance of BIM models for structural steel detailing.This program allows users to create a precise BIM model that includes the necessary elements (sections, plates, bolts, butt welds and anchorage) to define the structure. For the results output the program provides shop drawings in DSTV format.

CYPE Connect

CYPE Connect can model and analyse, in addition to steel element connections, connections between timber structural elements as well as steel-to-timber connections, using the finite element method. This application uses the OpenSees calculation engine.

StruBIM Uploader

"StruBIM Uploader" is an application developed by CYPE, with which structural models can be incorporated into Open BIM projects that are located on the BIMserver.center platform, and this way enabling a connection with visualisation, analysis and post-processing programs of other developers.
