StruBIM Embedded Walls M04

Set of tools for analysing and designing embedded walls.

Includes:

Original price was: R$ 12.562,00.Current price is: R$ 8.794,00.

Description:

StruBIM Embedded Walls M04 provides a solution for analysing and designing embedded walls for both buildings and civil works. It covers various types of embedded walls, such as reinforced concrete embedded walls, piles, mini piles, steel sheet piles and generic sheet piles. The analysis and drawing of slip circles when checking the global stability can also be carried out. It also offers a tool for BIM modelling and reinforcement detailing of reinforced concrete structural elements. This solution provides advanced tools to increase productivity and efficiency when designing embedded walls.

Analysis and design according to standards

CYPE's software includes a wide range of standards from various countries around the world within its native features, allowing users to design and check their projects with greater speed and accuracy.

What's included?

02 PROGRAMS - 04 MODULES

MCD

This module is used in StruBIM Embedded Walls for analysing and tracing slip circles in the global stability check.

MUG

This is the core module for using StruBIM Embedded Walls and is a prerequisite for running the program, as well as acquiring other modules.

MUH

In StruBIM Embedded Walls, this module is used for the analysis, design and reinforcement of reinforced concrete walls, concrete piles and mini piles.

MUT

In StruBIM Embedded Walls this module is used for the analysis and design of steel sheet piles from the "ArcelorMittal" catalogue and steel sheet piles with generic sections.

StruBIM Embedded Walls

StruBIM Embedded Wall is an application for designing and checking different types of embedded walls (diaphragm walls, piled retaining walls, mini piled retaining walls, steel pile walls and generic embedded walls) for building and public works.

StruBIM Rebar

StruBIM Rebar is a program with which users can model the reinforcement of reinforced concrete structural elements in the BIM model.
